Cut to Length Lines Automatic Feeding System
In the realm of metal processing equipment, Hebei Yowin machinery Technology Co., Ltd. stands as a reliable wholesaler, offering top-of-the-line cut to length machine solutions. At the heart of our advanced cutting systems lies the automatic feeding system, a critical component that optimizes efficiency and precision in metal processing. This article delves into the features, benefits, and technical prowess of our automatic feeding systems, highlighting how they elevate the performance of cut to length operations.
The Significance of Automatic Feeding System in Cut to Length Lines
The automatic feeding system is a game-changer for Hebei Yowin machinery Technology Co., Ltd.’s cut to length lines. In metal processing, the ability to feed materials accurately and continuously is essential for maintaining productivity and minimizing errors. Our automatic feeding systems are engineered to handle various metal coils and sheets, ensuring smooth and consistent material flow into the cut to length machine. By reducing manual intervention and streamlining the feeding process, these systems enhance the overall efficiency of automatic cut to length operations, making them indispensable for modern manufacturing facilities.
|
No |
Name |
Parameter |
|
1 |
Control model |
PLC DC control |
|
2 |
Materials |
Carbon steel |
|
3 |
Yield strength |
≤550 Mpa |
|
4 |
Thickness |
0.5-4.5 mm |
|
5 |
Width |
500-1500 mm |
|
6 |
Coil I.D. |
Φ480-520 mm(Φ508mm) |
|
7 |
Coil O.D. |
≤Φ1600mm |
|
8 |
Coil weight |
≤20T |
|
9 |
Line speed |
≤25 m/min |
|
10 |
Cutting speed |
it can cut about 1-2 pieces for 10m per minute; it can cut about 3 pieces for 6m per minute; it can cut about 4-5 pieces for 3m per minute; it can cut about 5-6 pieces for 2m per minute; it can cut about 7-8 pieces for 1m per minute; |
|
11 |
Diameter of leveling rollers |
Φ95 mm |
|
12 |
Straightener rollers |
17pcs |
|
13 |
Material of leveling roller |
GCr15 |
|
14 |
Harness |
HRC56°-60° |
|
15 |
Material of cutter blade |
H13K |
|
16 |
Diagonal tolerance |
±2mm(L=2m) |
|
17 |
Length tolerance |
±1.5mm(L=2m) |
|
18 |
Straighten precision |
±1mm |
|
19 |
Power |
380V/50HZ/3PH |
|
20 |
area of the whole line |
25m(L)X7m(W) |
|
21 |
The direction of whole line |
From right to left |
|
22 |
The color |
Blue |
|
23 |
Total capacity |
Around 110KW |
How Automatic Feeding System Enhances the Efficiency of Cut to Length Machine
Hebei Yowin machinery Technology Co., Ltd.’s automatic feeding system significantly boosts the efficiency of our cut to length machine. The system’s intelligent sensors and controls precisely measure and regulate the speed and tension of the incoming material, preventing jams and ensuring accurate cutting lengths. With the ability to handle heavy-duty coils and high-speed processing, our automatic cut to length solutions powered by advanced feeding systems can process large volumes of metal in a short time. This not only increases production capacity but also reduces labor costs associated with manual material handling.
Key Features of Automatic Cut to Length Lines with Feeding System
Our automatic cut to length products equipped with automatic feeding systems offer several remarkable features:
- High Precision Control: Advanced servo motors and sensors ensure accurate material positioning and feeding, resulting in precise cut lengths.
- Versatile Material Handling: Capable of handling different types of metals, including steel, aluminum, and copper, with varying thicknesses and widths.
- User-Friendly Interface: Intuitive control panels allow operators to easily set parameters and monitor the feeding process in real-time.
- Safety Mechanisms:Integrated safety features such as emergency stop buttons and protective barriers safeguard operators during operation.
Hebei Yowin machinery Technology Co., Ltd.’s Engineering Excellence in Feeding Systems for Cut to Length Lines
As a leading wholesaler, we prioritize engineering excellence in our automatic feeding systems for cut to length lines:
- Customized Design: Our team designs feeding systems tailored to the specific requirements of differentcut to length machine models and production needs.
- Quality Components: We source high-grade components to ensure durability and reliable performance, even under continuous heavy use.
- Testing and Validation: Each feeding system undergoes rigorous testing to verify its accuracy, stability, and compatibility with the overall cut to length line.
- After-Sales Support:We provide comprehensive after-sales services, including installation guidance, maintenance training, and technical assistance.
Cut to Length Lines FAQS
Why is an automatic feeding system crucial for cut to length machines?
An automatic feeding system is crucial for cut to length machines as it ensures continuous and accurate material supply. Hebei Yowin machinery Technology Co., Ltd.’s systems eliminate manual errors, reduce downtime, and enhance productivity. By precisely controlling the feeding process, they enable automatic cut to length operations to run smoothly, improving the overall efficiency of metal processing.
How does the automatic feeding system improve the precision of cut to length lines?
The automatic feeding system in our cut to length lines uses advanced sensors and servo motors to precisely position the material. This accurate positioning, combined with real-time monitoring and adjustment, ensures that each cut is of the exact desired length. As a result, our automatic cut to length solutions deliver highly precise results, meeting the stringent requirements of various industries.
What types of materials can the automatic cut to length feeding system handle?
Hebei Yowin machinery Technology Co., Ltd.’s automatic feeding systems for cut to length machine and cut to length lines are designed to handle a wide range of materials. They can process different metals, including carbon steel, stainless steel, aluminum, and copper, regardless of their thickness or width, making them suitable for diverse manufacturing applications.
Can the automatic cut to length feeding system be customized for specific production needs?
Yes, our team at Hebei Yowin machinery Technology Co., Ltd. can customize the automatic feeding system for automatic cut to length setups. We take into account factors such as material type, production volume, and cut length requirements to design a feeding system that perfectly fits each client’s unique production needs.
How do we ensure safe international shipping of cut to length lines?
For international shipping of cut to length lines with automatic feeding systems, we use sturdy, customized packaging to protect the equipment. Hebei Yowin machinery Technology Co., Ltd. partners with reliable shipping carriers and provides ocean bills of lading for smooth customs clearance. Our logistics team monitors each shipment to ensure the equipment arrives in optimal condition, ready for immediate installation.
